NFE31PT222Z1E9L Murata Electronics North America NFE31PT222Z1E9L label picture NFE31PT222Z1E9L real image
Same model may have multiple batches, images only for reference.
NFE31PT222Z1E9L Murata Electronics North America NFE31PT222Z1E9L label picture NFE31PT222Z1E9L real image
NFE31PT222Z1E9L Murata Electronics North America NFE31PT222Z1E9L label picture NFE31PT222Z1E9L real image
Same model may have multiple batches, images only for reference.

NFE31PT222Z1E9L

Part No NFE31PT222Z1E9L
Manufacturer Murata Electronics North America
Catalog EMI/RFI Filters (LC, RC Networks)
Description FILTER LC(T) 2200PF SMD
Datasheet
NFE31PT222Z1E9L Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Filters
Manufacturer Murata Electronics North America
Packaging Reel - TR
Status Active
Type Low Pass
Filter Order 3rd
Technology LC (T-Type)
Number of Channels 1
Current 6A
Values C = 2200pF
ESD Protection No
Temperature Range - Operating -40°C to 85°C
Applications General Purpose
Voltage Rating 25V
Mounting SMD (SMT)
Dimension 0.126" L x 0.063" W (3.20mm x 1.60mm)
Height 0.069" (1.75mm)
Win Source Part Number 025229-NFE31PT222Z1E9L
Family Name NFE31P
Introduction Date March 29, 2000
ECCN EAR99
Country of Origin Japan
Halogen Free Compliant
Estimated EOL Date 2023
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian NFE31PT222Z1E9L CAD Model

Description

The NFE31PT222Z1E9L is a low-pass filter manufactured by Murata Electronics North America.

  • Supply and Demand Status: Balanced
  • Mounting Type: SMD
  • Voltage Rating: 25V
  • Current: 6A
  • Center/Cutoff Frequency: -
  • Filter Order: 3rd
  • Resistance Channel: Ohms
  • Capacitance Value: 2200pF
  • Applications: General Purpose
