Same model may have multiple batches, images only for reference.
90130-3124 Real Image
Same model may have multiple batches, images only for reference.

90130-3124

Part No 90130-3124
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description AMP-LATCH 622 SER; RightAngle Cable Mount IDC Conn Plug; 24Way; 2 Row; 2.54mm Pitch
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Color Black
Connector Type Male Pin
Contact Material Brass
Contact Mating Length 6.7564 mm
Contact Plating Tin
Country of Origin SK
Current Rating 3 A
Gender Male
Glow Wire Compliant Non-compliant
Housing Color Black
Housing Material Polyester
Lead Free Yes
Lead Pitch 2.54 mm
Maximum Operating Temperature 125 °C
Max Voltage Rating (DC) 350.35 kV
Min Operating Temperature -55 °C
Mount Through Hole
Number of Circuits 24
Number of Contacts 24
Number of Pins 24
Number of Positions 24
Number of Rows 2
Orientation Right Angle
Pitch 2.54 mm
Plating Tin
RoHS Compliant
Row Spacing 2.54 mm
Termination Solder
Voltage Rating 350 V
Voltage Rating (AC) 350 V
Voltage Rating (DC) 350 V
Win Source Part Number 1037985-90130-3124
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian 90130-3124 CAD Model

Description

The Molex, LLC 1037985-90130-3124 is a high-quality circular connector housing that is suitable for various applications.

  • Positions: 24
  • Pitch: 2.54 mm
  • Connector Type: Male Pin
  • Rows: 2
  • Termination: Solder
  • Contact Material: Brass
  • Voltage Rating: 350 V
  • Current Rating: 3 A
  • Housing Material: Polyester
  • Contact Plating: Tin
  • Maximum Operating Temperature: 125 °C
  • Minimum Operating Temperature: -55 °C
