90120-0923 Real Image
Same model may have multiple batches, images only for reference.

90120-0923

Part No 90120-0923
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description Header Connector, PCB Mount, RECEPT, 3 Contacts, PIN, 0.1 Pitch, PC TAIL Terminal RoHS Compliant: Yes
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Contact Gender Male
Contact Material Brass
Contact Plating Gold
Country of Origin SK
Current Rating 3 A
Glow Wire Compliant Non-compliant
Halogen Free Not Halogen Free
Housing Material Polyester
Lead Length 2.9 mm
Mating Post Length 6.75 mm
Mount Through Hole
Number of Circuits 2
Number of Contacts 3
Number of Positions 3
Number of Rows 1
Orientation Vertical
Pitch 2.54 mm
Plating Nickel
RoHS Compliant
Termination Solder
Voltage Rating 350 V
Voltage Rating (AC) 350 V
Win Source Part Number 1144043-90120-0923
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian 90120-0923 CAD Model

Description

The Molex 90120-0923 is a circular connector housing with 3 positions and a pitch of 2.54 mm.

  • Positions: 3
  • Pitch: 2.54 mm
  • Rows: Single
  • Termination Style: Solder
  • Contact Material: Brass
  • Contact Plating: Gold
  • Housing Material: Polyester
  • Voltage Rating: 350V AC
  • Current Rating: 3A
  • Mounting Type: Through Hole
  • Orientation: Vertical
