70553-0007 Real Image
Same model may have multiple batches, images only for reference.

70553-0007

Part No 70553-0007
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description Conn Shrouded Header (4 Sides) HDR 8 POS 2.54mm Solder RA Side Entry Thru-Hole SL™ Tube
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Color Black
Contact Material Bronze
Contact Plating Gold
Contact Resistance 30 mΩ
Country of Origin US
Current Rating 3 A
ELV Compliant
Flammability Rating UL94 V-0
Gender Male
Glow Wire Compliant Non-compliant
Housing Color Black
Housing Material Thermoplastic
Insulation Resistance 1 GΩ
Lead Free Yes
Lead Pitch 2.54 mm
Material Brass
Maximum Operating Temperature 105 °C
Min Operating Temperature -40 °C
Mount Through Hole
Number of Circuits 8
Number of Contacts 8
Number of Positions 8
Number of Rows 1
Orientation Right Angle
Pitch 2.54 mm
Plating Tin
Radiation Hardening No
REACH SVHC Unknown
RoHS Compliant
Termination Through Hole
Voltage Rating 250 V
Voltage Rating (DC) 250 V
Win Source Part Number 1010039-70553-0007
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian 70553-0007 CAD Model

Description

The Molex, LLC 1010039-70553-0007 is an 8 position, 2.54mm pitch, black colored male through-hole connector.

  • Positions: 8
  • Pitch: 2.54mm
  • Color: black
  • Orientation: right angle
  • Row: 1
  • Contact Material: bronze
  • Housing Material: thermoplastic
  • Voltage Rating: 250V
  • Current Rating: 3A
  • Contact Resistance: 30 mΩ
  • Insulation Resistance: 1 GΩ
  • RoHS Compliant: Yes
  • Working Temperature Range: -40°C to 105°C
  • Widely Used in: circular connector housings
