70247-2051 Real Image
Same model may have multiple batches, images only for reference.

70247-2051

Part No 70247-2051
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description Conn Unshrouded Header HDR 20 POS 2.54mm Solder RA Thru-Hole Carton
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Color Black
Connector Type Male Pin
Contact Gender Male
Contact Material Bronze
Contact Mating Length 6.096 mm
Contact Plating Gold
Country of Origin SK
Current Rating 2.5 A
Depth 6.3 mm
ELV Compliant
Flammability Rating UL94 V-0
Gender Male
Glow Wire Compliant Non-compliant
Height 7.6 mm
Housing Color Black
Housing Material Polyester
Insulation Resistance 12 GΩ
Lead Free Yes
Lead Length 3.05 mm
Lead Pitch 2.54 mm
Length 8.65 mm
Material Polyester
Mating Post Length 6.1 mm
Max Current Rating 2 A
Maximum Operating Temperature 120 °C
Max Voltage Rating (AC) 125 V
Max Voltage Rating (DC) 250 V
Min Operating Temperature -55 °C
Mount Surface Mount, Through Hole
Number of Circuits 20
Number of Contacts 20
Number of Positions 20
Number of Rows 2
Orientation Right Angle
Pitch 2.54 mm
Plating Tin
Radiation Hardening No
REACH SVHC No SVHC
RoHS Compliant
Row Spacing 2.54 mm
Termination Solder
Voltage Rating (DC) 250 V
Win Source Part Number 1012940-70247-2051
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian 70247-2051 CAD Model

Description

The Molex, LLC electronic component is a product with a manufacturer part number of 1012940-70247-2051.

  • Positions: 20
  • Pitch: 2.54mm
  • Color: Black
  • Connector Type: Male pin
  • Rows: Two
  • Row Spacing: 2.54mm
  • Termination: Solder
  • Contact Mating Length: 6.096mm
  • Contact Material: Bronze
  • Current Rating: 2.5A
  • Voltage Rating: 250V
  • Supply and Demand Status: Shortage
  • Mounting Type: Surface mount and through-hole
  • RoHS: Compliant
  • Maximum Operating Temperature: 120 °C
