Same model may have multiple batches, images only for reference.
55917-3010 Real Image
Same model may have multiple batches, images only for reference.

55917-3010

Part No 55917-3010
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description 2.00mm Pitch MicroClasp Wire-to-Board Header, Dual Row, Vertical, 30 Circuits, with PCB Locator
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Color Natural
Connector Type Male Pin
Contact Material Brass
Contact Mating Length 3.81 mm
Contact Plating Tin
Contact Resistance 20 mΩ
Country of Origin VN
Current Rating 3 A
Depth 11.5 mm
Fastening Type Latch
Housing Color White
Housing Material Polybutylene
Insulation Resistance 1 GΩ
Lead Pitch 2 mm
Length 33.4 mm
Maximum Operating Temperature 85 °C
Max Voltage Rating (AC) 250 V
Max Voltage Rating (DC) 250 V
Min Operating Temperature -25 °C
Mount Through Hole
Number of Circuits 28
Number of Positions 30
Number of Rows 2
Orientation Vertical
Pitch 2.0066 mm
Plating Tin
Radiation Hardening No
RoHS Compliant
Row Spacing 5.0038 mm
Termination Solder
Voltage Rating (DC) 250 V
Win Source Part Number 1023127-55917-3010
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian 55917-3010 CAD Model

Description

The 1023127-55917-3010 is a circular connector housing that is designed for various applications manufactured by Molex.

  • Positions: 30
  • Pitch: 2.0066 mm
  • Connector Type: Male Pin
  • Rows: 2
  • Row Spacing: 5.0038 mm
  • Termination: Solder
  • Fastening Type: Latch
  • Contact Mating Length: 3.81 mm
  • Win Source Part Number: 1023127-55917-3010
