Same model may have multiple batches, images only for reference.
53398-1471 Real Image
Same model may have multiple batches, images only for reference.

53398-1471

Part No 53398-1471
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description 1.25mm (.049") Pitch PicoBlade Header, Surface Mount, Vertical, Lead-free, 14 Circuits
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Ambient Temperature Range High 105 °C
Body Plating Tin
Color Natural
Contact Material Tin
Contact Plating Tin
Contact Resistance 20 mΩ
Country of Origin MY
Current Rating 1 A
Depth 3.7 mm
Flammability Rating UL94 V-0
Gender Male
Glow Wire Compliant Non-compliant
Height 4.7 mm
Housing Color Natural
Housing Material Nylon
Insulation Resistance 100 MΩ
Lead Free Yes
Lead Pitch 1.25 mm
Length 22.6 mm
Maximum Operating Temperature 85 °C
Min Operating Temperature -40 °C
Mount Surface Mount
Number of Circuits 14
Number of Contacts 14
Number of Poles 14
Number of Positions 14
Number of Rows 1
Orientation Vertical
Packaging Cut Tape
Pitch 1.25 mm
Plating Tin
Radiation Hardening No
REACH SVHC Unknown
RoHS Compliant
Termination Solder
Voltage Rating 125 V
Voltage Rating (AC) 125 V
Voltage Rating (DC) 125 V
Width 3.7 mm
Working Voltage 125 V
Win Source Part Number 970651-53398-1471
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian 53398-1471 CAD Model

Description

The 970651-53398-1471 is a circular connector housing manufactured by Molex, LLC.

  • Positions: 14
  • Pitch: 1.25mm
  • Voltage Rating: 125V
  • Current Rating: 1A
  • Housing Material: nylon
  • Orientation: vertical
  • Contact Plating: tin
  • Lead-Free: yes
  • RoHS: compliant
  • Maximum Operating Temperature: 85°C
