53398-1271 Real Image
Same model may have multiple batches, images only for reference.

53398-1271

Part No 53398-1271
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description Connector Accessories 12 POS Rectangular Strain Relief Nylon Black
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Body Plating Tin
Color Natural
Contact Material Tin
Contact Plating Tin
Contact Resistance 20 mΩ
Country of Origin MY
Current Rating 1 A
Flammability Rating UL94 V-0
Gender Male
Glow Wire Compliant Non-compliant
Height 4.7 mm
Housing Color Natural
Housing Material Nylon
Insulation Resistance 100 MΩ
Lead Free Yes
Lead Pitch 1.25 mm
Length 20.1 mm
Maximum Operating Temperature 85 °C
Min Operating Temperature -40 °C
Mount Surface Mount
Number of Circuits 12
Number of Contacts 12
Number of Pins 12
Number of Positions 12
Number of Rows 1
Orientation Vertical
Packaging Cut Tape
Pitch 1.25 mm
Plating Tin
Radiation Hardening No
REACH SVHC No SVHC
RoHS Compliant
Termination Solder
Voltage Rating 125 V
Voltage Rating (AC) 125 V
Voltage Rating (DC) 125 V
Width 3.7 mm
Working Voltage 125 V
Win Source Part Number 991897-53398-1271
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian 53398-1271 CAD Model

Description

The Molex 991897-53398-1271 is a 12-position, 1.25mm pitch, male connector that is terminated by soldering.

  • Package: cut tape
  • Housing Material: nylon
  • Color: natural
  • HTSUS: 8536.69.4040
  • RoHS: compliant
  • REACH SVHC: not available
  • Flammability Rating: UL94 V-0
  • Alternative Parts: 1-350374-9, 53398-1071, 53398-1471, DF13C-12P-1.25V(21), M40-30112460533981271, 53398-1271, 533981271 and 533981271
