52991-0208 Real Image
Same model may have multiple batches, images only for reference.

52991-0208

Part No 52991-0208
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description SLIMSTACK Series 0.5mm 20 Way 2 Row Straight PCB Socket Smnt Board to Board
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Connector Type Receptacle
Contact Material Bronze
Contact Plating Gold
Country of Origin US
Current Rating 500 mA
ELV Compliant
Gender Receptacle
Glow Wire Compliant Non-compliant
Halogen Free Low Halogen
Height 2.27 mm
Housing Material Polymer
Insulation Resistance 100 MΩ
Lead Free Yes
Lead Pitch 500 µm
Length 8.8 mm
Maximum Operating Temperature 105 °C
Min Operating Temperature -40 °C
Mount Surface Mount
Number of Circuits 20
Number of Contacts 20
Number of Pins 20
Number of Positions 20
Number of Rows 2
Orientation Vertical, Right Angle
Packaging Cut Tape
Pitch 500 µm
Plating Gold
Radiation Hardening No
REACH SVHC No SVHC
RoHS Compliant
Row Spacing 4 mm
Termination SMD/SMT, Solder
Voltage Rating 50 V
Voltage Rating (DC) 50 V
Width 5.4 mm
Win Source Part Number 976942-52991-0208
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian 52991-0208 CAD Model

Description

The Molex 976942-52991-0208 is a 20-position receptacle connector that is designed for use in a wide range of applications.

  • Positions: 20
  • Pitch: 500µm
  • Contact Material: bronze
  • Contact Plating: gold
  • Voltage Rating: 50V
  • Current Rating: 500mA
  • Housing Material: polymer
  • Low Halogen: Yes
  • RoHS Compliant: Yes
  • Mounting Type: surface mount technology
