Same model may have multiple batches, images only for reference.
502225-0801 Real Image
Same model may have multiple batches, images only for reference.

502225-0801

Part No 502225-0801
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description Conn Power RCP 10Power/25Signal POS 2.75mm/2mm Solder/Press Fit ST Thru-Hole 85 Terminal 1 Port Box
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Color Black
Connector Type Male Pin
Contact Material Nickel, Tin
Contact Plating Tin
Country of Origin JP
Current Rating 6 A
Depth 49 mm
Fastening Type Latch
Gender Male
Glow Wire Compliant Non-compliant
Height 27.3 mm
Housing Color Black
Housing Material PBT
Maximum Operating Temperature 105 °C
Max Voltage Rating (DC) 14 V
Min Operating Temperature -40 °C
Mount Through Hole
Number of Circuits 80
Number of Contacts 80
Number of Ports 2
Number of Positions 80
Number of Rows 4
Orientation Right Angle
Pitch 2.5 mm
Plating Tin
Radiation Hardening No
REACH SVHC Unknown
RoHS Compliant
Termination Solder
Voltage Rating 14 V
Voltage Rating (DC) 14 V
Width 99 mm
Win Source Part Number 1021551-502225-0801
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian 502225-0801 CAD Model

Description

This is a black male pin connector manufactured by Molex LLC.

  • Win Source Part Number: 1021551-502225-0801
  • Positions: 80
  • Pitch: 2.5 mm
  • Rows: 4
  • Termination: Solder
  • Fastening Type: Latch
  • Voltage Rating: 14 V
  • Current Rating: 6 A
  • Contacts: 80
  • Gender: Male
  • Housing Material: PBT
  • Orientation: Right-Angled
  • Height: 27.3 mm
  • Width: 99 mm
  • RoHS Compliant: Yes
  • Supply and Demand Status: Shortage
