501645-1020 Real Image
Same model may have multiple batches, images only for reference.

501645-1020

Part No 501645-1020
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description Conn Shrouded Header (4 Sides) HDR 10 POS 2mm Solder ST Thru-Hole iGrid™ Frame
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Color Natural
Connector Type Male Pin
Contact Material Brass
Contact Plating Gold
Country of Origin VN
Current Rating 300 mA
Depth 8.2 mm
Fastening Type Latch
Gender Male
Glow Wire Compliant Non-compliant
Height 11.75 mm
Housing Color Natural
Housing Material Polyamide
Lead Pitch 2 mm
Length 12 mm
Max Operating Temperature 85 °C
Max Voltage Rating (AC) 250 V
Max Voltage Rating (DC) 250 V
Min Operating Temperature -40 °C
Mount Through Hole
Number of Circuits 10
Number of Contacts 10
Number of Positions 10
Number of Rows 2
Orientation Vertical, Right Angle
Pitch 2 mm
Plating Tin
RoHS Compliant
Row Spacing 2.0066 mm
Termination Solder
Voltage Rating 250 V
Voltage Rating (DC) 250 V
Win Source Part Number 1130780-501645-1020
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian 501645-1020 CAD Model

Description

The Molex, LLC 501645-1020 circular connector housing is a high-quality electronic component designed for reliable performance.

  • Manufacturer: Molex, LLC
  • Part Number: 501645-1020
  • Positions: 10
  • Pitch: 2mm
  • Connector Type: male pin
  • Rows: two
  • Row Spacing: 2.0066mm
  • Termination: solder
  • Fastening Type: latch
  • Contact Material: brass
  • Contact Plating: gold
  • Voltage Rating: 250V
  • Current Rating: 300mA
  • Mounting: through-hole
  • Height: 11.75mm
  • RoHS: compliant
  • ECCN: EAR99
