Same model may have multiple batches, images only for reference.
5015943011 Real Image
Same model may have multiple batches, images only for reference.

5015943011

Part No 5015943011
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description Conn Board to Board PL 30 POS 0.4mm Solder ST SMD SlimStack™ T/R
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Color Black
Connector Type Plug
Contact Material Bronze
Contact Plating Gold
Country of Origin JP
Current Rating 300 mA
Depth 3.4 mm
ELV Compliant
Flammability Rating UL94 V-0
Gender Male
Glow Wire Compliant Non-compliant
Halogen Free Low Halogen
Housing Color Black
Housing Material Thermoplastic
Lead Pitch 400 µm
Length 9.1 mm
Mated Stacking Heights 900 µm
Material Bronze
Max Operating Temperature 85 °C
Max Voltage Rating (AC) 50 V
Max Voltage Rating (DC) 5.05 kV
Min Operating Temperature -25 °C
Mount Surface Mount
Number of Circuits 30
Number of Contacts 30
Number of Positions 30
Number of Rows 2
Orientation Vertical
Pitch 400 µm
Radiation Hardening No
REACH SVHC No SVHC
RoHS Compliant
Stack Height 900 µm
Termination Solder
Voltage Rating (AC) 50 V
Voltage Rating (DC) 50 V
Win Source Part Number 1217654-5015943011
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian 5015943011 CAD Model

Description

The 1217654-5015943011 electronic component is manufactured by Molex, LLC.

  • Supply and Demand Status: The supply and demand status of the 1217654-5015943011 is limited.
  • Positions: This component has a number of positions of 30
  • Pitch: and a pitch of 400 µm.
  • Color: It has a black color
  • Connector Type: and a plug connector type.
  • Current Rating: The 1217654-5015943011 has a current rating of 300 mA
  • Mated Stacking Height: and a mated stacking height of 900 µm.
  • Housing Material: It has a housing material made of thermoplastic
  • RoHS Compliance: and is compliant with RoHS.
