The 501571-2007 is a Molex Pico-Clasp connector housing. This is a wire-to-board connector system designed for compact and secure connections in tight spaces.

Applications

• Consumer Electronics: Used in smartphones, tablets, and other portable devices for internal connections.
• Medical Devices: Employed in medical equipment where space is limited and reliable connections are essential.
• Industrial Equipment: Integrated into control systems and automation equipment.
• Automotive Electronics: Used for connecting sensors and other components in vehicles.
• Robotics: Employed in robotic systems for internal wiring and signal connections.

Features

• Number of Circuits: 7. Specifies the number of individual contacts the housing can accommodate.
• Pitch: 1.00mm. Indicates the spacing between adjacent contacts.
• Mating Style: Wire-to-Board. Designed to connect wires to a printed circuit board.
• Locking Feature: Includes a locking mechanism to ensure a secure connection.
• Material: Typically made of high-temperature thermoplastic for durability and reliability.

Benefits

• Compact Size: 1.00mm pitch allows for high-density connections in tight spaces.
• Secure Connection: Locking feature prevents accidental disconnections.
• Reliable Performance: Designed for long-term reliability and stable performance.
• Easy to Use: Simple to assemble with appropriate crimp terminals and mating connectors.
• Durable: Constructed from robust materials to withstand harsh environments.

Additional Details

The 501571-2007 Pico-Clasp connector housing is an ideal solution for applications requiring compact and reliable wire-to-board connections. Its 1.00mm pitch allows for high-density board layouts, while the locking feature ensures a secure connection in demanding environments. Molex is a trusted manufacturer of connectors, guaranteeing the quality and performance of this product. It is essential to use compatible Molex crimp terminals and mating headers designed for the Pico-Clasp series. Proper crimping techniques and tools are crucial for ensuring a reliable connection. This connector is commonly found in consumer electronics, medical devices, and industrial automation systems. It provides a robust and space-saving solution for connecting wires to PCBs.
