Same model may have multiple batches, images only for reference.
39-00-0435 Real Image
Same model may have multiple batches, images only for reference.

39-00-0435

Part No 39-00-0435
Manufacturer Molex, LLC
Catalog Card Edge Connectors - Edgeboard Connectors
Description Mini-Fit Female Crimp Terminal Selective Gold (Au) and Selective Tin (Sn) over Nickel (Ni) 22-28 AWG Bag
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Connector Type Connector, PCB, Signal
Contact Gender Female
Contact Material Brass
Contact Plating Gold
Contact Resistance 20 mΩ
Country of Origin US
Current Rating 5 A
Depth 2.3 mm
Gender Female
Halogen Free Low Halogen
Height 2.3 mm
Insulation Non-Insulated
Length 14.7 mm
Max Current Rating 9 A
Maximum Operating Temperature 105 °C
Min Operating Temperature -40 °C
Mount Cable
Orientation Straight
Plating Tin
Radiation Hardening No
RoHS Compliant
Shielding Unshielded
Termination Crimp
Voltage Rating 600 V
Wire/Cable Gauge 28 AWG
Wire Gauge (Max) 22 AWG
Wire Gauge (Min) 28 AWG
Win Source Part Number 999906-39-00-0435
Categories Card Edge Connectors - Edgeboard Connectors
Manufacturer Molex, LLC
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian 39-00-0435 CAD Model

Description

The Molex 999906-39-00-0435 is a female PCB signal connector with a crimp termination. This unshielded connector has a voltage rating of 600 V and a current rating of 5 A.

  • Gender: Female
  • Type: PCB signal connector
  • Termination: Crimp
  • Shielded: Unshielded
  • Voltage Rating: 600 V
  • Current Rating: 5 A
  • Orientation: Straight
  • Contact Plating: Gold
  • Contact Resistance: 20 mΩ
  • Insulated: Non-insulated
  • Height: 2.3 mm
  • Depth: 2.3 mm
  • Length: 14.7 mm
  • Plating: Tin
  • Wire/Cable Gauge: 28 AWG to 22 AWG
  • Category: Card edge connector, edgeboard connectors
  • RoHS: Compliant
