Product Name: Headers & Wire Housings MINI-FIT JR HDR 04P RA 94V-2

Product Number: 0039301040

Manufacturer: Molex, LLC

The Molex 0039301040 is a 4-position, right-angle, MINI-FIT Jr. header with a black housing and gold-plated contacts. It is made from flame-retardant nylon 66 plastic and has a 94V-2 flammability rating. The header is designed to mate with MINI-FIT Jr. wire housings and is compatible with a wide range of wire gauges.

The MINI-FIT Jr. series is a family of wire-to-board connectors that are designed for use in space-constrained applications. The connectors are small and lightweight, but they offer a high current rating and a reliable connection. MINI-FIT Jr. connectors are used in a variety of industries, including automotive, consumer electronics, industrial automation, and medical devices.

Features

• 4-position, right-angle header
• Black housing with gold-plated contacts
• 94V-2 flammability rating
• Compatible with MINI-FIT Jr. wire housings
• High current rating and reliable connection

Applications

• Automotive
• Consumer electronics
• Industrial automation
• Medical devices
• Other space-constrained applications

Benefits

• Space-saving design
• High current rating
• Reliable connection
• Easy to use and install
• Cost-effective

Specifications

• Number of positions: 4
• Connector type: Header
• Orientation: Right angle
• Housing material: Nylon 66
• Housing color: Black
• Contact material: Brass
• Contact plating: Gold
• Flammability rating: 94V-2
• Current rating: 19.2A per contact
• Voltage rating: 600VAC
• Wire gauge: 18-24 AWG

Installation

The Molex 0039301040 header can be installed on a PCB using a variety of methods, including soldering, surface mount, and through-hole mounting. The header is designed to be compatible with a wide range of PCB thicknesses.

Conclusion

The Molex 0039301040 header is a high-quality, reliable connector that is ideal for use in space-constrained applications. It offers a high current rating and a reliable connection, making it a good choice for a variety of industries.
