TCCH-80+ Mini-Circuits TCCH-80+ Real Image TCCH-80+ real image 2 TCCH-80+ label picture TCCH-80+ Real Image1 TCCH-80+ Real Image2 TCCH-80+ Real Image3 TCCH-80+ Real Image4 TCCH-80+ Real Image5
Same model may have multiple batches, images only for reference.
TCCH-80+ Mini-Circuits TCCH-80+ Real Image TCCH-80+ real image 2 TCCH-80+ label picture TCCH-80+ Real Image1 TCCH-80+ Real Image2 TCCH-80+ Real Image3 TCCH-80+ Real Image4 TCCH-80+ Real Image5
TCCH-80+ Mini-Circuits TCCH-80+ Real Image TCCH-80+ real image 2 TCCH-80+ label picture TCCH-80+ Real Image1 TCCH-80+ Real Image2 TCCH-80+ Real Image3 TCCH-80+ Real Image4 TCCH-80+ Real Image5
Same model may have multiple batches, images only for reference.

TCCH-80+

Part No TCCH-80+
Manufacturer Mini-Circuits
Catalog Fixed Inductors
Description FIXED IND 4UH 200MA 100MOHM SMD
Datasheet
TCCH-80+ Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes - Fixed Inductors
Mfr Mini-Circuits
Package Tape & Reel
Product Status Active
Type Wirewound
Inductance 4 µH
Current Rating (Amps) 200 mA
Shielding Unshielded
DC Resistance (DCR) 100mOhm
Temperature Range - Operating -40°C ~ 85°C
Mounting Type Surface Mount
Package / Case Horizontal, 4 PC Pad
Supplier Device Package Horizontal, 4 PC Pad
Size / Dimension 0.150" L x 0.150" W (3.81mm x 3.81mm)
Height - Seated (Max) 0.150" (3.80mm)
Standard Package 2,000 pcs
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8504.50.8000
Win Source Part Number 712478-TCCH-80+
Ultra Librarian 3D Model Ultra Librarian TCCH-80+ CAD Model

Description

The 712478-TCCH-80+ is a fixed inductor used in various applications.

  • Type: Wirewound
  • Inductance: 4 µH
  • Size: 0.150" L x 0.150" W (3.81mm x 3.81mm)
  • Shielded: Unshielded
  • Seated Height (Max): 0.150" (3.80mm)
  • Package: Tape and Reel
  • Standard Quantity: 2,000 pieces
  • DCR: 100mOhm
  • Current Rating: 200mA
  • Temperature Range: -40°C to 85°C
  • MSL Level: 1 (Unlimited)
  • HTSUS Code: 8504.50.8000
  • Manufacturer: Mini-Circuits
  • Status: Active
