The N25Q064A13EW7D0F is a 64 Mb (Megabit) Serial Flash Memory device produced by Micron Technology Inc. It belongs to the N25Q family, which is recognized for its high performance, low power consumption, and reliability. This makes it suitable for a variety of embedded applications. This particular part number specifies certain configuration parameters, packaging, and temperature ratings.

Applications

• Embedded Systems: Utilized for storing firmware, boot code, configuration data, and application code.
• Consumer Electronics: Integrated in products such as digital cameras, MP3 players, and e-readers for storing system software and user data.
• Industrial Automation: Employed in industrial control systems, programmable logic controllers (PLCs), and human-machine interfaces (HMIs) for storing application code and settings.
• Networking Equipment: Used in routers, switches, and wireless access points for storing bootloaders, configuration files, and firmware updates.
• Medical Devices: Incorporated in medical instruments for storing calibration data, patient information, and operating software.

Features

• Memory Size: 64 Mb (8MB) of storage capacity.
• Interface: Serial Peripheral Interface (SPI) for easy connection with microcontrollers and processors.
• Supply Voltage: Operates on a single 2.7V to 3.6V power supply.
• Page Program: Supports page program operations for efficient and fast data writing.
• Sector Erase: Offers sector erase functionality, enabling flexible memory management.
• Block Erase: Provides block erase capability for efficient bulk data erasure.
• Security Features: Includes security features like password protection and block locking to protect against unauthorized access.
• Operating Temperature: Designed to operate within a wide industrial temperature range for reliable performance in various environments.
• Quad SPI Support: Supports Quad SPI (QSPI) mode for enhanced data throughput.

Benefits

• High Performance: Provides fast read, write, and erase speeds, contributing to quick system response.
• Low Power Consumption: Minimizes power usage, making it suitable for battery-powered devices and energy-conscious applications.
• Compact Size: Small package size allows for easy integration into space-constrained environments.
• Reliable Data Storage: Ensures data integrity and long-term data retention.
• Simplified System Design: SPI interface streamlines connections to microcontrollers and other host devices.
• Cost-Effective Solution: Offers a cost-efficient solution for non-volatile memory needs.
• Enhanced Security: Helps safeguard sensitive data from unauthorized modifications or access.

Additional Details

The N25Q064A13EW7D0F is produced using advanced CMOS technology, which contributes to its low power consumption and high reliability. It is available in various package options to suit different application needs. The SPI interface supports various modes including standard SPI, Dual SPI, and Quad SPI, allowing for flexible data transfer rates. The device includes a deep power-down mode, further reducing power consumption during periods of inactivity. Its combination of robust features makes it an ideal choice for embedded systems requiring reliable and secure non-volatile memory.
