Microchip Technology USB3290-FH Product Overview

The USB3290-FH from Microchip Technology is a highly-integrated USB 2.0 High-Speed peripheral controller, designed to enable developers to add USB connectivity to their embedded systems with minimal effort and cost. This versatile device is ideal for applications across a diverse range of industries, including consumer electronics, communication, and industrial automation.

Key Features

• USB 2.0 Compliance: The USB3290-FH is fully compliant with the USB 2.0 specification, ensuring reliable operation at High-Speed (480 Mbps).
• UTMI+ Interface: It features a UTMI+ Level 3 transceiver interface, providing a direct connection to the USB transceiver without the need for additional components.
• Low Power Consumption: Designed for power-sensitive applications, this controller consumes minimal power, making it suitable for battery-powered devices.
• Flexible Clocking Options: The device supports a wide range of external clock frequencies, providing flexibility in system design.
• Small Form Factor: Available in a compact 32-QFN (5x5 mm) package, the USB3290-FH is ideal for space-constrained applications.

Performance and Integration

The USB3290-FH boasts an efficient architecture that is optimized for low-power operation and minimal processor overhead. It integrates a Serial Interface Engine (SIE), FIFO memory, and a USB transceiver into a single chip, reducing the number of external components required and simplifying the design process.

Applications

With its robust feature set and ease of integration, the USB3290-FH is suitable for a wide array of applications, such as:

• Portable medical devices
• Point-of-sale terminals
• Industrial control systems
• Data acquisition devices
• Gaming and entertainment systems

Support and Resources

Microchip Technology provides extensive support and resources to help designers implement the USB3290-FH in their projects. This includes detailed datasheets, application notes, and software drivers to facilitate rapid development and integration.
