Microchip SST39VF020-70-4C-B3KE Flash Memory

The SST39VF020-70-4C-B3KE is a high-performance, 2-Megabit Flash memory device designed and manufactured by Microchip Technology. This non-volatile memory chip offers a cost-effective solution for storage requirements in a wide range of electronic applications, from embedded systems to general-purpose computing. Its robust design and reliability make it an excellent choice for firmware storage, code shadowing, and data retention in an array of products.

Key Features

• Memory Organization: The SST39VF020-70-4C-B3KE is organized as 256K x8 (2Mbit), providing ample space for code and data storage.
• Performance: With an access time of 70ns, this Flash memory device ensures quick read operations, enhancing the overall performance of the system it is integrated into.
• Operating Voltage: It operates within a voltage range of 4.5V to 5.5V, which is suitable for a broad spectrum of applications and compatible with most 5V microcontrollers.
• Endurance: The device is rated for a minimum of 100,000 erase and program cycles, ensuring a long operational lifespan for applications that require frequent data updates.
• Data Retention: It offers a data retention period of at least 100 years, making it a reliable choice for long-term data storage.
• Temperature Range: This memory chip is designed to operate over an extended industrial temperature range, from -40°C to +85°C, allowing its use in harsh environmental conditions.

Programming and Erasure

The SST39VF020-70-4C-B3KE supports sector-erase and block-erase capabilities, providing flexibility for programming and updating data. The chip's byte-program function allows for byte-level updates, which is particularly useful for applications that require frequent modifications of small data sets.

Compatibility and Usage

With its industry-standard pinout, the SST39VF020-70-4C-B3KE is easy to integrate into existing designs. It is often used in applications such as digital cameras, MP3 players, modems, and other consumer electronics that require reliable and durable storage solutions. Its compatibility with JEDEC standards ensures that it can easily replace equivalent parts from other manufacturers, providing designers with flexibility and ease of sourcing.

Overall, the SST39VF020-70-4C-B3KE from Microchip Technology represents a blend of performance, reliability, and versatility, making it a top choice for designers and engineers seeking a dependable Flash memory solution.
