Categories Integrated Circuits
Manufacturer Microchip Technology
Packaging Reel - TR
Status Active
Type Simple Reset/Power-On Reset
Number of Voltages Monitored 1
Output Complementary
Reset Active High
Reset Timeout 140 ms Minimum
Voltage - Threshold Adjustable/Selectable
Temperature Range - Operating -40°C to 85°C (TA)
Mounting SMD (SMT)
Case / Package SOT-23-5
Win Source Part Number 109671-MIC2776H-YM5-TR
Ultra Librarian 3D Model Ultra Librarian MIC2776H-YM5-TR CAD Model

Description

Product Overview: MIC2776H-YM5-TR by Microchip Technology

The MIC2776H-YM5-TR is a high-performance, dual-voltage microprocessor reset circuit designed by Microchip Technology, a leading provider of smart, connected, and secure embedded control solutions. This compact and highly reliable component is specifically engineered to monitor power supplies in microprocessor and digital systems, providing a significant layer of protection against power failures and brownout conditions.

Key Features

  • Dual Voltage Monitoring: This device is capable of monitoring two voltage thresholds, making it versatile for systems that operate on different voltage levels or require tracking of both core and I/O voltages.
  • Programmable Delay: The MIC2776H-YM5-TR includes an adjustable delay time for the reset signal, allowing designers to tailor the reset timing to match specific system requirements.
  • Low Power Consumption: With its low quiescent current, this device is an excellent choice for battery-operated and portable applications, helping to extend battery life and reduce overall power usage.
  • Manual Reset Input: An additional manual reset input provides a means to initiate a system reset externally, offering greater control over system behavior and diagnostics.
  • Compact SOT-23-5 Package: The small footprint of the SOT-23-5 package makes it ideal for space-constrained applications, allowing for integration into compact PCB designs without sacrificing performance.

Applications

The MIC2776H-YM5-TR is suitable for a wide range of applications within the consumer, industrial, and automotive sectors. Its robust design ensures reliable operation in environments that require precise voltage monitoring and control, such as:

  • Embedded Systems
  • Microcontrollers and Microprocessors
  • Portable Electronics
  • Automotive Electronics
  • Telecommunication Systems

Quality and Reliability

Microchip Technology is known for its commitment to quality, and the MIC2776H-YM5-TR is no exception. It is manufactured to high standards, ensuring consistent performance and durability. The device is also available in tape and reel packaging (denoted by the 'TR' suffix), facilitating efficient handling and placement during the manufacturing process.

In summary, the MIC2776H-YM5-TR from Microchip Technology is a versatile and reliable solution for system voltage monitoring and reset functions. Its combination of features, including dual voltage monitoring, programmable delay, and low power consumption, make it a valuable component for safeguarding critical electronic systems.
