Categories Integrated Circuits
Manufacturer Microchip Technology
Packaging Tube
Output Type Transistor Driver
Function Step-Down
Topology Buck
Output Phases 1
Supply Voltage 4.5V ~ 32V
Switching Frequency 300kHz
Duty Cycle (Maximum) 86%
Synchronous Rectifier Yes
Clock Sync Yes
Control Features Enable, Soft Start
Temperature Range - Operating -40°C ~ 85°C
Manufacturer Package 16-SSOP
Supplier Device Package 16-SSOP
Family Part Number MIC2182
Manufacturer Pack Quantity 77
MSL Level 2 (1 Year)
Win Source Part Number 1222098-MIC2182-5.0YSM
Manufacturer Homepage www.micrel.com
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian MIC2182-5.0YSM CAD Model

Description

The MIC2182-5.0YSM is a robust, high-performance DC-DC converter from Microchip Technology, designed to deliver a fixed 5.0V output from a wide input voltage range. This highly efficient device is a part of Microchip’s MIC2182 series, known for their reliability and versatility in a variety of applications, including telecommunications, industrial systems, and consumer electronics.

Key Features

  • Output Voltage: Fixed at 5.0V, providing a stable power supply for 5V-operated devices.
  • High Efficiency: Designed to maximize power conversion efficiency, reducing energy loss and heat generation.
  • Wide Input Voltage Range: Accommodates a broad range of input voltages, ensuring compatibility with various power sources.
  • Thermal Protection: Integrated thermal shutdown feature protects the device from overheating, enhancing its longevity and reliability.
  • Compact Size: The small footprint of the package allows for easy integration into space-constrained designs.
  • Low Quiescent Current: Minimizes standby power consumption, making it ideal for battery-powered applications.

Applications

The MIC2182-5.0YSM is suitable for a wide array of applications that require a reliable and efficient 5V power supply. It's particularly well-suited for:

  • Portable Devices
  • Networking Hardware
  • Industrial Control Systems
  • Telecommunication Equipment
  • Consumer Electronics

Product Specifications

Parameter Value Output Voltage (V) 5.0 Input Voltage Range (V) Varies Package / Case YSM Operating Temperature Specified Range

In summary, the MIC2182-5.0YSM from Microchip Technology is a reliable, efficient, and versatile DC-DC converter that meets the needs of various electronic devices and systems. Its robust design and comprehensive feature set make it an excellent choice for designers looking for a dependable power solution.
