Microchip Technology MCP4017T-503E/LT Digital Potentiometer

The MCP4017T-503E/LT is a high-performance digital potentiometer designed and manufactured by Microchip Technology, a leading provider of smart, connected, and secure embedded control solutions. This compact, 7-bit (128 wiper steps), non-volatile digital potentiometer is an ideal solution for applications requiring precise resistance tuning in a small form factor.

Key Features:

• Resistance Options: The MCP4017T-503E/LT offers a resistance value of 50kΩ, providing flexibility for various applications that require a specific resistance range.
• Interface: Equipped with an I2C™Compatible interface, this digital potentiometer allows for easy communication with microcontrollers and other digital systems, facilitating seamless integration into complex designs.
• Non-Volatile Memory: The device features non-volatile memory to retain the wiper position at power-down, ensuring the system retains its configuration across power cycles.
• Low Temperature Coefficient: With a low typical temperature coefficient of 75 ppm/°C, the MCP4017T-503E/LT ensures stable performance over a wide temperature range.
• Power Supply: It operates from a single 2.7V to 5.5V power supply, making it suitable for both 3V and 5V systems.
• Extended Temperature Range: The device is designed to perform reliably in extreme conditions with an operating temperature range of -40°C to +125°C.
• Compact Package: The MCP4017T-503E/LT comes in a tiny, 6-lead SC-70 package, which is ideal for space-constrained applications.
• Applications: Its applications are diverse and include calibration and adjustment of system parameters, sensor trimming, audio control, and feedback systems, among others.

Product Summary:

The MCP4017T-503E/LT from Microchip Technology represents a blend of precision, durability, and versatility, making it a suitable choice for designers who need a reliable digital potentiometer for their electronic projects. With its robust feature set and compact footprint, this digital potentiometer is poised to deliver top-notch performance in a myriad of applications where variable resistance is needed to control a circuit's behavior dynamically.
