Products specifications

Categories Integrated Circuits
Manufacturer Microchip Technology
Packaging Tube/Rail
Status Active
Type Infrared Encoder/Decoder
Analog Supply Voltage 2.5 V to 5.5 V
Digital Supply Voltage 2.5 V to 5.5 V
Mounting SMD (SMT)
Case / Package 14-SOIC
Win Source Part Number 083904-MCP2120-I/SL
Family Name MCP2120
Introduction Date May 29, 2001
ECCN EAR99
Country of Origin Thailand
Halogen Free Compliant
Estimated EOL Date 2024
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian MCP2120-I/SL CAD Model

Description

Microchip Technology's MCP2120-I/SL: A Versatile IRDA Standard Encoder/Decoder

The MCP2120-I/SL is a highly integrated Encoder/Decoder (ENDEC) from Microchip Technology, designed to offer a simple and efficient way to implement the physical layer protocol as defined by the Infrared Data Association (IrDA). This compact device is housed in an SOIC-14 package, making it suitable for space-constrained applications where reliable infrared communication is required.

As part of Microchip's renowned line of communication products, the MCP2120-I/SL operates in the 2.4V to 5.5V voltage range, ensuring compatibility with a variety of microcontrollers and digital systems. It has been engineered to interface with standard UARTs to facilitate the conversion of UART data streams into IrDA-compliant infrared data and vice versa. This feature allows for seamless integration into existing designs, reducing development time and complexity.

The MCP2120-I/SL supports IrDA speeds up to 115.2 kbps, making it suitable for applications that require moderate data transfer rates without sacrificing power efficiency. Its built-in features, such as the programmable baud rate generator and low-power shutdown mode, contribute to its versatility and make it an excellent choice for battery-operated devices.

Moreover, the device includes a built-in 3/16 bit encoder/decoder as per the IrDA specification. This ensures the MCP2120-I/SL can handle the necessary pulse shaping and timing required for infrared communication, thus offloading these tasks from the host processor. The product also offers a carrier frequency of 38kHz, which is the standard for most consumer IR devices, enhancing its interoperability.

With its industrial temperature range of -40°C to +85°C, the MCP2120-I/SL is robust enough to operate in harsh environments, making it suitable for a wide array of applications, including laptops, printers, PDAs, and other mobile devices where wireless infrared communication is advantageous.

For developers looking to implement IrDA functionality with minimal hassle, the MCP2120-I/SL from Microchip Technology stands as a reliable and cost-effective solution that ensures compliance with the IrDA physical layer standards while providing the flexibility needed for diverse application requirements.
