The ATA6570-GNQW1 is a high-performance CAN (Controller Area Network) transceiver from Microchip Technology, designed to facilitate communication in automotive and industrial applications. This device serves as an interface between a CAN protocol controller and the physical two-wire CAN bus. It is well-suited for high-speed CAN applications, supporting the ISO 11898-2:2016 standard, and offers an ideal solution for networking in cars, trucks, buses, and heavy-duty vehicles.

Key Features

• Data Transmission: Supports CAN FD (Flexible Data-rate) for data rates up to 5 Mbit/s, ensuring efficient and fast data transfer in complex systems.
• Protection: Comes with features such as thermal protection, short-circuit protection, and voltage regulators, making it reliable in harsh environments.
• Low Power Modes: Offers several low-power modes including Sleep and Standby, to reduce power consumption when the network is idle.
• Wake-up Capability: Can be woken up from Sleep mode via the CAN bus, ensuring that the device is only active when needed.

Applications

• Automotive Networks
• Industrial Automation Systems
• Building Automation
• Heavy Machinery Control

Technical Specifications

• Supply Voltage: 4.5V to 5.5V
• Operating Temperature Range: -40°C to +150°C
• Package: QFN
• Quality Grade: Automotive
• Compliance: AEC-Q100 qualified

The ATA6570-GNQW1 is a testament to Microchip's commitment to providing robust and versatile communication solutions. Its advanced features and compliance with automotive-grade standards make it an essential component for developers looking to build reliable CAN networks in vehicles and industrial settings.
