Product Overview: 1N4748E3/TR13 by Microchip Technology

The 1N4748E3/TR13 is a robust, precision Zener diode manufactured by Microchip Technology, a leader in the field of microcontroller and analog semiconductors. This electronic component is designed to provide a precise voltage reference and is commonly utilized in voltage regulation applications due to its consistent and reliable performance.

Key Features

• Voltage Regulation: The 1N4748E3/TR13 offers a nominal Zener voltage of 22V, making it suitable for a wide range of voltage regulation tasks in electronic circuits.
• Power Dissipation: This Zener diode comes with a power dissipation of 1W, which allows it to handle a moderate amount of power while maintaining its voltage regulation capabilities.
• Tolerance: The device features a standard tolerance of ±5%, ensuring accurate voltage regulation for critical applications.
• Package: Supplied in a DO-204AL package, also known as an axial leaded DO-41, the 1N4748E3/TR13 is designed for through-hole mounting, making it easy to integrate into various PCB designs.
• Temperature Stability: The Zener diode operates effectively over a wide temperature range, maintaining stability and performance under varying environmental conditions.
• Tape and Reel Packaging: The TR13 suffix indicates that the device is provided in a tape and reel format, which is optimal for automated assembly processes, enhancing production efficiency for manufacturers.

Applications

The 1N4748E3/TR13 is versatile and can be used in a multitude of electronic circuits and applications, including:

• Power supply circuits
• Voltage reference in analog-to-digital converters
• Surge protection
• Overvoltage protection
• Waveform shaping

With its precise voltage regulation and reliable performance, the 1N4748E3/TR13 from Microchip Technology is a crucial component for designers and engineers looking to create stable and durable electronic products. Whether you're developing consumer electronics, industrial control systems, or automotive applications, this Zener diode is engineered to meet the stringent requirements of modern electronic devices.
