ESDSLC16VLB-TP ESDSLC16VLB-TP real image24477
Same model may have multiple batches, images only for reference.
ESDSLC16VLB-TP ESDSLC16VLB-TP real image24477
ESDSLC16VLB-TP ESDSLC16VLB-TP real image24477
Same model may have multiple batches, images only for reference.

ESDSLC16VLB-TP

Part No ESDSLC16VLB-TP
Manufacturer Micro Commercial Co
Catalog TVS - Diodes
Description TVS DIODE 16VWM 30VC DFN1006-2 / 30V Clamp 1A (8/20μs) Ipp Tvs Diode Surface Mount 2-DFN1006
Datasheet
ESDSLC16VLB-TP Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Circuit Protection - Transient Voltage Suppressors (TVS) - TVS Diodes
Mfr Micro Commercial Co
Package Tape & Reel
Product Status Active
Type Zener
Bidirectional Channels 1
Voltage - Reverse Standoff (Typ) 16V (Max)
Voltage - Breakdown (Min) 18V
Voltage - Clamping (Max) @ Ipp 30V
Current - Peak Pulse (10/1000µs) 1A (8/20µs)
Power - Peak Pulse 30W
Power Line Protection No
Applications General Purpose
Capacitance @ Frequency 0.7pF @ 1MHz
Temperature Range - Operating -55°C ~ 125°C (TJ)
Mounting Type Surface Mount
Package / Case 0402 (1006 Metric)
Supplier Device Package 2-DFN1006
Base Product Number ESDSLC16
Standard Package 10,000 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 852918-ESDSLC16VLB-TP
Ultra Librarian 3D Model Ultra Librarian ESDSLC16VLB-TP CAD Model

Description

The ESDSLC16VLB-TP is a TVS diode from Micro Commercial Co. It is a discrete semiconductor product commonly used for transient voltage suppression.

  • Product Type: TVS Diode
  • TVS Type: Zener
  • Application: General Purpose
  • Reverse Standoff Voltage: 16V
  • Breakdown Voltage: 18V
  • Clamping Voltage (Ipp): 30V
  • Peak Pulse Power: 30W
  • Mounting Type: Surface Mount
  • Package: 0402 (1006 Metric)
  • Temperature Range: -55°C to 125°C
  • Product Status: Active
  • Packaging: Tape and Reel
  • Standard Package Quantity: 10,000 pcs
