The SR2080 is a Schottky Barrier Rectifier designed for high-efficiency rectification. It is manufactured by MIC GROUP RECTIFIERS and is commonly used in applications requiring low forward voltage drop and fast switching speeds.

Applications

• Switching power supplies
• Freewheeling diodes
• Polarity protection applications
• DC-DC converters
• Instrumentation

Features

• High surge current capability
• Low forward voltage drop, typically 0.75V at 20A
• High-frequency operation
• Guard ring structure for stress protection
• High reliability

Benefits

• Improved efficiency in power conversion circuits
• Reduced power dissipation due to low forward voltage drop
• Enhanced system reliability due to high surge current capability
• Compact design due to its small footprint
• Protection against voltage transients

Technical Specifications

The SR2080 has a maximum repetitive peak reverse voltage of 80V. It features a maximum average forward rectified current of 20A. The maximum peak forward surge current is 175A. The operating junction temperature ranges from -65°C to +150°C. The device is typically encapsulated in a TO-220AC package.

The low forward voltage drop of the SR2080 significantly contributes to reducing power loss during conduction, making it a preferred choice in high-efficiency power supplies. Its fast switching speed also minimizes switching losses, further enhancing overall system performance.

The robust design and construction of the SR2080 ensure high reliability and long-term stability in various operating conditions. The device is also designed to withstand high surge currents, providing additional protection against overcurrent events and enhancing the robustness of the system.
