The MLX90360LGO-ACD-000 is a robust Triaxis® position sensor IC designed and manufactured by Melexis Microelectronic Systems. It is used for measuring rotary or linear displacement, providing a contactless sensing solution. Leveraging Melexis's patented Triaxis® Hall technology, this sensor offers high accuracy, reliability, and immunity to stray magnetic fields, making it suitable for demanding automotive, industrial, and consumer applications.

Applications

• Automotive Steering Systems: Provides steering angle measurement in electronic power steering (EPS) systems.
• Valve Position Sensing: Measures the position of valves in industrial and automotive applications.
• Robotics: Used for joint position feedback in robotic arms and actuators.
• Consumer Electronics: Rotary position detection in appliances and control knobs.
• Industrial Automation: Measures linear or rotary position in various automated systems.

Features

• Triaxis® Hall Technology: Enables three-dimensional magnetic field sensing for accurate position measurement.
• Contactless Sensing: Offers wear-free operation and long service life.
• High Accuracy: Provides precise and reliable position data.
• Immunity to Stray Fields: Robust performance even in the presence of external magnetic fields.
• Programmable Parameters: Allows customization of the sensor characteristics to suit specific application requirements.

Benefits

• Improved System Performance: High-accuracy position sensing enables precise control and improved overall system performance.
• Enhanced Reliability: Contactless sensing and robust design ensure long-term reliability in harsh environments.
• Flexibility: Programmable parameters and various output options provide design flexibility.
• Reduced Maintenance: Contactless operation eliminates wear and reduces maintenance requirements.
• Simplified Integration: Easy-to-use interface simplifies the integration process.

Additional Details

The MLX90360LGO-ACD-000 sensor is available in a small outline package (typically SOIC or TSSOP). It operates over a wide temperature range, making it suitable for both automotive and industrial applications. The output signal can be either analog or digital, depending on the configuration. It also includes diagnostic features for detecting sensor faults and ensuring system integrity. Melexis provides comprehensive documentation and support for this sensor, including application notes and reference designs. The Triaxis® technology provides inherent immunity to external magnetic fields, which is crucial in applications where stray magnetic fields are present. This sensor is commonly used in safety-critical applications due to its high reliability and accuracy.
