Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Maxim Integrated
Packaging Reel - TR
Status Active
Type Transceiver
Protocol RS232, RS422, RS485
Number of Drivers/Receivers 2/2
Duplex Full
Receiver Hysteresis 500mV
Data Rate 10Mbps
Supply Voltage - Operating 3 V to 5.5 V
Temperature Range - Operating 0°C to 70°C
Mounting SMD (SMT)
Case / Package 20-SSOP
Win Source Part Number 1067378-MAX3160CAP+T
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name MAX3160
Introduction Date September 01, 2000
ECCN EAR99
Halogen Free Compliant
Estimated EOL Date 2024
Ultra Librarian 3D Model Ultra Librarian MAX3160CAP+T CAD Model

Description

Maxim Integrated MAX3160CAP+T RS-232/RS-485/RS-422 Multiprotocol Transceiver

The MAX3160CAP+T from Maxim Integrated is a versatile and highly integrated multiprotocol transceiver designed to facilitate communication in industrial, networking, and telecommunication applications. This compact, surface-mount device supports RS-232, RS-485, and RS-422 protocols, making it an ideal solution for systems that require flexibility in interfacing with different serial communication standards.

With its wide voltage range of 3.0V to 5.5V, the MAX3160CAP+T is suitable for operation in a variety of power environments, ensuring compatibility with both legacy and modern equipment. The transceiver features a 1µA shutdown mode that significantly reduces power consumption when not in active use, thus extending the life of battery-powered devices.

The MAX3160CAP+T is engineered to support data rates up to 250kbps in RS-485/RS-422 mode and up to 1Mbps in RS-232 mode, providing the speed needed for a broad range of communication tasks. The device also includes a half-duplex/full-duplex selector that allows for easy switching between communication modes, further enhancing its versatility.

Protection is a key aspect of the MAX3160CAP+T design. The transceiver comes with integrated protection against electrostatic discharge (ESD) up to ±15kV, safeguarding the device from common electrical overstress conditions. Additionally, the device's fail-safe circuitry ensures a logic-high receiver output when the inputs are open or shorted, which prevents system errors during line faults or idle periods.

The MAX3160CAP+T is available in a 20-pin SSOP package, which is conducive to space-constrained applications. Its operating temperature range of -40°C to +85°C allows for reliable performance in harsh environments, ensuring that communication remains consistent and stable across various conditions.

Whether you are designing a point-of-sale system, a network switch, or an industrial control unit, the MAX3160CAP+T multiprotocol transceiver offers the flexibility, speed, and reliability required to maintain robust serial communications within your product.
