The MAX3100CEE+T is a highly integrated UART (Universal Asynchronous Receiver-Transmitter) with an on-chip crystal oscillator and a SPI/MICROWIRE-compatible serial interface. Manufactured by Maxim Integrated, a leader in analog and mixed-signal engineering, this device is designed to add an extra serial port to microcontrollers and other digital systems. It's a perfect solution for applications where UART ports are at a premium.

Key Features

• Integrated Crystal Oscillator: The MAX3100CEE+T includes an onboard crystal oscillator which simplifies design and reduces external component count.
• SPI/MICROWIRE Interface: Offers compatibility with a wide range of microcontrollers and processors, ensuring easy integration into existing designs.
• Automatic Hardware and Software Flow Control: This feature greatly simplifies the management of data flow and enhances reliability in communication.
• IrDA SIR-Compliant: With built-in support for IrDA SIR (Serial Infrared) communication protocols, this UART is ideal for wireless infrared data links.
• Low Power Consumption: The device is optimized for low-power operation, making it suitable for battery-powered and portable applications.

Applications

The MAX3100CEE+T is versatile and can be used in a variety of applications. It's particularly well-suited for portable devices, PDAs, and laptops where additional UARTs are needed. Its infrared communication capability makes it a good choice for remote controls, wireless keyboards, and other IrDA-compliant devices. Additionally, its low power consumption and integrated features make it ideal for industrial controls, POS terminals, and network equipment.

Technical Specifications

• Supply Voltage Range: 3.0V to 5.5V
• Operating Temperature Range: -40°C to +85°C
• Package Type: 16-Pin QSOP
• Lead-Free and RoHS Compliant

Overall, the MAX3100CEE+T from Maxim Integrated offers a reliable and efficient solution for expanding UART capabilities with minimal additional components and straightforward integration.
