Products specifications

Categories Integrated Circuits
Manufacturer Maxim Integrated
Packaging Reel - TR
Status Active
Type Transceiver
Protocol RS422, RS485
Number of Drivers/Receivers 1/1
Duplex Full
Receiver Hysteresis 100mV
Data Rate 16Mbps
Supply Voltage - Operating 3 V to 3.6 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 14-SOIC
Win Source Part Number 021405-MAX3079EESD+T
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name MAX3079E
Introduction Date October 01, 2002
ECCN EAR99
Country of Origin Malaysia, Philippines, Taiwan, Thailand, United States of America
Halogen Free Compliant
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian MAX3079EESD+T CAD Model

Description

Maxim Integrated MAX3079EESD+T RS-485/RS-422 Transceiver

The MAX3079EESD+T is a robust RS-485/RS-422 transceiver module from Maxim Integrated, designed to facilitate bidirectional data communication on multipoint bus transmission lines. It is a high-speed, low-power transceiver that is ideal for long-distance and high-speed applications where signal integrity and reliability are paramount.

This transceiver is capable of achieving data rates up to 20Mbps, making it suitable for high-speed data transfer requirements in industrial, telecom, and networking environments. It operates from a single 3.3V supply, which is beneficial for systems where power efficiency is critical. The MAX3079EESD+T is available in an 8-pin NSOIC package, which is optimized for reduced space on printed circuit boards.

One of the key features of the MAX3079EESD+T is its enhanced electrostatic discharge (ESD) protection. It can withstand ±15kV ESD strikes without sustaining damage, in accordance with the Human Body Model, providing robust protection against static electricity and other voltage spikes that can occur in harsh industrial environments.

The device also includes fail-safe circuitry that ensures a logic-high receiver output if the receiver inputs are open, shorted, or idle, thus providing additional safety and reliability in the event of a fault or disconnection in the communication line. Furthermore, the MAX3079EESD+T has a half-duplex configuration, which means it can both transmit and receive data but not simultaneously, using a single twisted pair.

The MAX3079EESD+T also features thermal shutdown and current limiting to protect the device from damage due to excessive power dissipation or bus contention situations. With its extended temperature range of -40°C to +85°C, it is well-suited for operation in extreme conditions.

Overall, the Maxim Integrated MAX3079EESD+T is a reliable and high-performance solution for RS-485/RS-422 communication needs, offering robust protection features and high data rate capabilities, all within a compact and power-efficient design.
