Product Overview: Maxim Integrated MAX202ECSE+

The MAX202ECSE+ from Maxim Integrated is a robust, high-performance integrated circuit designed to facilitate serial communication in a variety of electronic devices. This IC is particularly well-suited for applications requiring reliable data transfer over RS-232 communication protocols, making it an essential component in the realm of serial connectivity.

Key Features

• Electrical Interface: The device is designed to convert TTL or CMOS logic levels to RS-232 and vice versa, enabling seamless communication between microcontrollers and serial ports.
• Electrostatic Discharge (ESD) Protection: The MAX202ECSE+ offers an impressive ESD protection level of ±15kV using the Human Body Model (HBM), ensuring the longevity and reliability of the device in harsh environments.
• Integrated Charge Pump: This feature allows the IC to generate RS-232 voltage levels from a single 5V supply, eliminating the need for additional power supplies and simplifying circuit design.
• Low Power Shutdown: An energy-saving shutdown mode reduces the power consumption of the device to just 1µW, making it an ideal choice for power-sensitive applications.
• Data Rate: The MAX202ECSE+ supports data rates up to 120kbps, providing fast and efficient serial communication.
• Receiver Hysteresis: Built-in hysteresis of 300mV on receiver inputs offers improved noise immunity and ensures stable data reception.

Applications

The versatility of the MAX202ECSE+ makes it suitable for a wide range of applications, including:

• Point-of-sale (POS) terminals
• Industrial control systems
• Data acquisition systems
• Modem interfaces
• Networking equipment

Package and Quality

The MAX202ECSE+ is offered in a 16-pin narrow SO package, which is both space-efficient and compatible with standard PCB layouts. Maxim Integrated's commitment to quality ensures that each IC meets stringent performance criteria, providing designers and engineers with a reliable and consistent solution for their RS-232 communication needs.
