The DS3232N is a precision, low-power Real-Time Clock (RTC) with an integrated temperature-compensated crystal oscillator (TCXO) and crystal. This high-accuracy RTC provides seconds, minutes, hours, day, date, month, and year information, with the added capability of leap year compensation valid up to 2100. Manufactured by Maxim Integrated, a leader in analog and mixed-signal products, the DS3232N is designed to provide a comprehensive timekeeping solution for a wide range of applications.
With an operating temperature range of -40°C to +85°C and a time accuracy of ±2ppm from 0°C to +40°C, the DS3232N stands out for its precision and reliability in various environments. The device integrates 236 bytes of battery-backed SRAM and 17 bytes of user-accessible nonvolatile storage, making it ideal for systems that require battery-backed nonvolatile timekeeping with additional memory support.
One of the key features of the DS3232N is its two programmable time-of-day alarms and a programmable square-wave output, offering versatility for a multitude of applications, including embedded systems, industrial time tracking, and data logging devices. Furthermore, the RTC provides a digital temperature sensor with ±3°C accuracy, which can be used for environment monitoring or system heat management.
The device communicates with a microcontroller via an I²C serial interface, with a maximum bus speed of 400kHz, ensuring easy integration into existing systems. The DS3232N comes in a 16-pin, 300-mil SO package, a standard footprint that is both space-saving and convenient for PCB design.
For power failure protection, the DS3232N includes an automatic power-fail detect and switch circuitry. When main power is lost, the device automatically switches to a backup supply, maintaining accurate timekeeping and preserving SRAM data. This feature is critical for applications where time data integrity is paramount during power loss scenarios.
In summary, the Maxim Integrated DS3232N Real-Time Clock offers high accuracy, low power consumption, and additional memory, making it a robust choice for applications requiring precise timekeeping and data retention capabilities.
