Product Overview: 71M6534H-IGT/F from Maxim Integrated

The 71M6534H-IGT/F is a highly integrated energy meter IC from Maxim Integrated, designed to provide precise energy measurement in a variety of applications. This advanced metering chip is ideal for residential smart meters, industrial meters, and energy monitoring systems, offering a comprehensive solution for energy measurement and data management.

Key Features

• High Accuracy: The 71M6534H-IGT/F delivers exceptional accuracy, meeting the stringent requirements of IEC and ANSI standards for energy metering.
• Integrated Memory: Equipped with an on-chip 32-bit compute engine and FLASH memory, it enables versatile tariff and data logging features, allowing for sophisticated energy management and billing schemes.
• Low Power Consumption: Designed for efficiency, it operates with low power consumption, making it suitable for battery-operated metering systems.
• Flexible Interface Options: With multiple communication interfaces, including UART, SPI, and I2C, this IC allows for easy integration with external microcontrollers and communication modules.
• On-Chip ADC: The integrated Analog-to-Digital Converter (ADC) provides direct interfacing to current sensors and voltage lines, facilitating the measurement process.
• Anti-Tampering Features: Advanced security and anti-tampering features ensure the integrity of metering data, protecting against fraudulent activities.

Applications

The 71M6534H-IGT/F is versatile and can be used in a wide range of energy metering applications including:

• Residential energy meters
• Commercial and industrial energy meters
• Sub-metering systems
• Smart grid infrastructure
• Portable energy monitors

Technical Specifications

Below are some of the technical specifications for the 71M6534H-IGT/F:

• Supply Voltage: 3.0V to 3.6V
• Operating Temperature: -40°C to +85°C
• Package: 100-pin LQFP

Maxim Integrated's commitment to reliability and innovation is evident in the 71M6534H-IGT/F, making it a smart choice for advanced energy metering solutions.
