MX29GL256EHT2I-90Q Macronix
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Macronix
Packaging Tray
Status Active
Memory Format FLASH
Technology FLASH - NOR
Memory Size 256Mb (32M x 8)
Access Time 90ns
Supply Voltage - Operating 2.7 V to 3.6 V
Temperature Range - Operating -40°C to 85°C (TA)
Mounting SMD (SMT)
Case / Package 56-TSOP
Win Source Part Number 059730-MX29GL256EHT2I-90Q
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name MX29GL256E
Introduction Date July 20, 2009
ECCN 3A991.b.1.a
Country of Origin Taiwan
Estimated EOL Date 2022
Ultra Librarian 3D Model Ultra Librarian MX29GL256EHT2I-90Q CAD Model

Description

The Macronix MX29GL256EHT2I-90Q is an integrated circuit that belongs to the memory family. It has a high popularity and a limited supply and demand status.

  • Function: Designed to store data in electronic devices
  • Memory Size: 256Mb
  • Technology: FLASH-NOR technology-based product
  • Access Time: 90ns
  • Case/Package: 56-TSOP case/package
  • Operating Temperature Range: -40°C to 85°C
