LX18-P150-5 Lumileds
Same model may have multiple batches, images only for reference.

LX18-P150-5

Part No LX18-P150-5
Manufacturer Lumileds
Catalog LED Lighting - White
Description LED LUXEON COOL WHITE 5000K 3SMD
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Lumileds
Packaging Reel
Color White, Cool
CCT (K) 5000K 5-Step MacAdam Ellipse
Flux at 85°C, Current - Test 106lm (Typ)
Current - Test 350mA
Voltage - Forward (Vf) (Typ) 2.76V
Lumens/Watt at Current - Test 110 lm/W
CRI (Color Rendering Index) 80
Current - Max 1A
Viewing Angle 120°
Mounting Style SMD
Manufacturer Package 1812 (4532 Metric)
Supplier Device Package 4530
Dimension 0.177" L x 0.120" W (4.49mm x 3.05mm)
Height - Seated (Maximum) 0.083" (2.10mm)
Thermal Resistance of Package 9°C/W
Manufacturer Pack Quantity 1,000
MSL Level 1 (Unlimited)
Popularity High
Supply and Demand Status Sufficient
Win Source Part Number 801003-LX18-P150-5
Ultra Librarian 3D Model Ultra Librarian LX18-P150-5 CAD Model

Description

The LX18-P150-5 is a white, cool LED component manufactured by Lumileds.

  • Package: 4530
  • Maximum Current: 1A
  • Viewing Angle: 120 degrees
  • Forward Voltage: 2.76V
  • Test Current: 350mA
  • CCT: 5000K
  • CRI: 80
  • Thermal Resistance: 9 degrees Celsius per watt
  • Length: 0.177 inches
  • Width: 0.120 inches
  • Height (Seated): 0.083 inches
  • Packaging: Reel
  • Manufacturer Pack Quantity: 1,000
  • MSL Level: 1 (Unlimited)
  • Flux @ 85°C (Test Current): 106lm (typ)
  • Lumens/Watt (Test Current): 110 lm/W
