Same model may have multiple batches, images only for reference.
T10120 Littelfuse Inc. – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

T10120

Part No T10120
Manufacturer Littelfuse Inc.
Catalog Time Delay Relays
Description On-Delay Time Delay Relay SPDT (1 Form C) 0.1 Min ~ 10 Min Delay Chassis Mount
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Littelfuse Inc.
Series T10
Packaging Bulk
Mounting Type Chassis Mount
Relay Type Solid State Relay
Function On-Delay
Circuit SPDT (1 Form C)
Delay Time 0.1 Min ~ 10 Min
Voltage - Supply 115VAC
Termination Style Screw Terminal
Timing Adjustment Method Screwdriver Slot
Timing Initiate Method Input Voltage
Base Product Number T1012
RoHS Status ROHS3 Compliant
MSL Level Not Applicable
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 9107.00.8000
Win Source Part Number 1478725-T10120
Ultra Librarian 3D Model Ultra Librarian T10120 CAD Model
