SRV05-4HTG Real Image SRV05-4HTG real image6457 SRV05-4HTG real image6458 SRV05-4HTG Real Image
Same model may have multiple batches, images only for reference.
SRV05-4HTG Real Image SRV05-4HTG real image6457 SRV05-4HTG real image6458 SRV05-4HTG Real Image
SRV05-4HTG Real Image SRV05-4HTG real image6457 SRV05-4HTG real image6458 SRV05-4HTG Real Image
Same model may have multiple batches, images only for reference.

SRV05-4HTG

Part No SRV05-4HTG
Manufacturer Littelfuse Inc.
Catalog TVS - Diodes
Description TVS DIODE 6VWM 15VC SOT23-6
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Circuit Protection
Manufacturer Littelfuse Inc.
Packaging Reel - TR
Status Active
Type Steering (Rail to Rail)
Unidirectional Channels 4
STAND-OFF Voltage (Vwm) 6V (Max)
Max Clamping Voltage 15V
Peak Pulse Current(Ippm) 10A (8/20μs)
Power Dissipation - Pd 150W
Power Line Protection Yes
Applications General Purpose
Temperature Range - Operating -40°C to 125°C (TJ)
Mounting SMD (SMT)
Case / Package SOT-23-6
Win Source Part Number 030806-SRV05-4HTG
Family Name SRV05-4H
Introduction Date February 02, 2005
ECCN EAR99
Country of Origin China, Malaysia, Thailand
Halogen Free Compliant
Estimated EOL Date 2022
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Computers & Computer Peripherals, Communications & Networking, Consumer Electronics, Medical, Portable Devices
Ultra Librarian 3D Model Ultra Librarian SRV05-4HTG CAD Model

Description

This electronic component is manufactured by Littelfuse Inc. and has a Win Source Part Number of 030806-SRV05-4HTG.

  • Type: steering (Rail to Rail)
  • Suitable For: general purpose applications
  • Mounting: SMD (SMT)
  • Channels: 4 unidirectional channels with power line protection
  • Family Name: SRV05-4H
  • Category: Circuit Protection
  • Temperature Range: -40°C to 125°C (TJ)
  • Case/Package: SOT-23-6
  • STAND-OFF Voltage (Vwm): 6V (Max)
  • Peak Pulse Current(Ippm): 10A (8/20μs)
  • Power Dissipation - Pd: 150W
  • Estimated EOL Date: 2022
  • Compliant With: Halogen Free
  • Part Status: common-used part
  • Used In: Computers & Computer Peripherals, Communications & Networking, Consumer Electronics, Medical, and Portable Devices.
