SMF6.5A Real Image SMF6.5A real image11072
Same model may have multiple batches, images only for reference.
SMF6.5A Real Image SMF6.5A real image11072
SMF6.5A Real Image SMF6.5A real image11072
Same model may have multiple batches, images only for reference.

SMF6.5A

Part No SMF6.5A
Manufacturer Littelfuse Inc.
Catalog TVS - Diodes
Description TVS DIODE 6.5VWM 11.2VC SOD123
Datasheet
SMF6.5A Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Circuit Protection
Manufacturer Littelfuse Inc.
Packaging Reel - TR
Status Active
Type Zener
Unidirectional Channels 1
STAND-OFF Voltage (Vwm) 6.5V
Minimum Breakdown Voltage 7.22V
Max Clamping Voltage 11.2V
Peak Pulse Current(Ippm) 17.9A
Power Dissipation - Pd 200W
Applications General Purpose
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package SOD-123F
Win Source Part Number 1098325-SMF6.5A
Popularity Medium
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian SMF6.5A CAD Model

Description

The Littelfuse Inc. 1098325-SMF6.5A is a SMD (SMT) zener diode with a stand-off voltage (Vwm) of 6.5V and a minimum breakdown voltage of 7.22V.

  • Stand-off Voltage (Vwm): 6.5V
  • Minimum Breakdown Voltage: 7.22V
  • Max Clamping Voltage: 11.2V
  • Peak Pulse Current (Ippm): 17.9A
  • Power Dissipation - Pd: 200W
  • Temperature Range: -55°C to 150°C (TJ)
  • Supply and Demand Status: sufficient
