SMDJ33CA

Name: SMDJ33CA
Brand: Littelfuse Inc.
SKU: 669039
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	SMDJ33CA
Manufacturer	Littelfuse Inc.
Catalog	TVS - Diodes
Description	TVS DIODE 33VWM 53.3VC DO214AB / 53.3V Clamp 56.3A Ipp Tvs Diode Surface Mount DO-214AB (SMCJ)
Datasheet	SMDJ33CA Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Circuit Protection - Transient Voltage Suppressors (TVS) - TVS Diodes
Mfr	Littelfuse Inc.
Series	SMDJ
Package	Tape & Reel
Product Status	Active
Type	Zener
Bidirectional Channels	1
Voltage - Reverse Standoff (Typ)	33V
Voltage - Breakdown (Min)	36.7V
Voltage - Clamping (Max) @ Ipp	53.3V
Current - Peak Pulse (10/1000µs)	56.3A
Power - Peak Pulse	3000W (3kW)
Power Line Protection	No
Applications	General Purpose
Temperature Range - Operating	-65°C ~ 150°C (TJ)
Mounting Type	Surface Mount
Package / Case	DO-214AB, SMC
Supplier Device Package	DO-214AB (SMCJ)
Standard Package	3,000 pcs
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8541.10.0080
California Prop 65	Warning Information
Win Source Part Number	669039-SMDJ33CA
Ultra Librarian 3D Model	Ultra Librarian SMDJ33CA CAD Model

Description

The SMDJ33CA is a TVS diode from Littelfuse Inc.

Mounting: Surface Mount
Package: DO-214AB, SMC
Packaging: Tape and Reel
Standard Package: 3,000 pcs
Type: Bidirectional Zener
Reverse Standoff Voltage: 33V
Breakdown Voltage: 36.7V
Clamping Voltage: 53.3V @ Peak Pulse Current
Peak Pulse Power: 3000W
Peak Pulse Current: 56.3A (10/1000µs)
Applications: Circuit Protection, Transient Voltage Suppressors
