Same model may have multiple batches, images only for reference.

SMDJ14A

Name: SMDJ14A
Brand: Littelfuse Inc.
SKU: 806431
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	SMDJ14A
Manufacturer	Littelfuse Inc.
Catalog	TVS - Diodes
Description	TVS DIODE 14V 23.2V DO214AB / SURFACE MOUNT TRANSIENT VOLTAGE SUPPRESSOR VOLTAGE-5.0 TO 170 Volts 3000 Watt Peak Pulse Power
Datasheet	SMDJ14A Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Manufacturer	Littelfuse Inc.
Packaging	Reel
Type	Zener
Unidirectional Channels	1
Voltage - Reverse Standoff (Typ)	14V
Voltage - Breakdown (Min)	15.6V
Voltage - Clamping (Maximum) at Ipp	23.2V
Current - Peak Pulse (10/1000μs)	129.3A
Power - Peak Pulse	3000W (3kW)
Power Line Protection	No
Applications	Use For General
Temperature Range - Operating	-65°C ~ 150°C
Mounting Style	SMD
Manufacturer Package	DO-214AB, SMC
Supplier Device Package	DO-214AB (SMCJ)
Manufacturer Pack Quantity	3,000
MSL Level	1 (Unlimited)
Popularity	Medium
Supply and Demand Status	Balance
Win Source Part Number	806431-SMDJ14A
Ultra Librarian 3D Model	Ultra Librarian SMDJ14A CAD Model

Alternative Products

Description

The Littelfuse Inc. Zener diode is a high-quality diode that offers reliable and efficient performance.

Voltage Reverse Standoff (Typ): 14V
Voltage Breakdown (Min): 15.6V
Operating Temperature: -65°C to 150°C
Supplier Device Package: DO-214AB (SMCJ)
Manufacturer Package: DO-214AB, SMC
Manufacturer Pack Quantity: 3,000
Voltage Clamping (Maximum) @ Ipp: 23.2V
Type: Zener
Channels: 1
