SMDJ12CA Real Image SMDJ12CA Real Image
Same model may have multiple batches, images only for reference.
SMDJ12CA Real Image SMDJ12CA Real Image
SMDJ12CA Real Image SMDJ12CA Real Image
Same model may have multiple batches, images only for reference.

SMDJ12CA

Part No SMDJ12CA
Manufacturer Littelfuse Inc.
Catalog TVS - Diodes
Description TVS DIODE 12VWM 19.9VC DO214AB
Datasheet
SMDJ12CA Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Circuit Protection - Transient Voltage Suppressors (TVS) - TVS Diodes
Mfr Littelfuse Inc.
Series SMDJ
Package Tape & Reel
Product Status Active
Type Zener
Bidirectional Channels 1
Voltage - Reverse Standoff (Typ) 12V
Voltage - Breakdown (Min) 13.3V
Voltage - Clamping (Max) @ Ipp 19.9V
Current - Peak Pulse (10/1000µs) 150.8A
Power - Peak Pulse 3000W (3kW)
Power Line Protection No
Applications General Purpose
Temperature Range - Operating -65°C ~ 150°C (TJ)
Mounting Type Surface Mount
Package / Case DO-214AB, SMC
Supplier Device Package DO-214AB (SMCJ)
Standard Package 3,000 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0080
California Prop 65 Warning Information
Win Source Part Number 669024-SMDJ12CA
Ultra Librarian 3D Model Ultra Librarian SMDJ12CA CAD Model

Description

The SMDJ12CA is a surface mount Zener type transient voltage suppressor diode that provides protection against voltage transients in electronic circuits. It is manufactured by Littelfuse Inc.

  • Series: SMDJ
  • Package: DO-214AB (SMC)
  • Reverse Standoff Voltage: 12V
  • Breakdown Voltage: 13.3V
  • Diode Type: Bidirectional
  • Clamping Voltage: 19.9V @ 10/1000µs
  • Peak Pulse Power: 3000W (3kW)
  • Mounting Type: Surface Mount
  • Packaging: Tape & Reel
  • Operating Temperature: -65°C to 150°C
  • Product Status: Active
  • Power Line Protection: No
  • California Proposition 65: Contains substances requiring caution
