SMCJ5.0CA Real Image SMCJ5.0CA label picture
Same model may have multiple batches, images only for reference.
SMCJ5.0CA Real Image SMCJ5.0CA label picture
SMCJ5.0CA Real Image SMCJ5.0CA label picture
Same model may have multiple batches, images only for reference.

SMCJ5.0CA

Part No SMCJ5.0CA
Manufacturer Littelfuse Inc.
Catalog TVS - Diodes
Description TVS DIODE 5VWM 9.2VC SMC
Datasheet
SMCJ5.0CA Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Circuit Protection
Manufacturer Littelfuse Inc.
Packaging Reel - TR
Status Active
Type Zener
Bidirectional Channels 1
STAND-OFF Voltage (Vwm) 5V
Minimum Breakdown Voltage 6.4V
Max Clamping Voltage 9.2V
Peak Pulse Current(Ippm) 163A
Power Dissipation - Pd 1500W (1.5kW)
Applications General Purpose
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package DO-214AB (SMCJ)
Win Source Part Number 084161-SMCJ5.0CA
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Communications & Networking, Computers & Computer Peripherals, Imaging, Video & Vision, Industrial
Ultra Librarian 3D Model Ultra Librarian SMCJ5.0CA CAD Model

Description

The Littelfuse Inc. 084161-SMCJ5.0CA is a Zener type circuit protection component that is widely used in general-purpose applications.

  • Manufacturer: Littelfuse Inc.
  • Application: General-Purpose
  • Case/Package: DO-214AB (SMCJ)
  • Channel Type: Bidirectional
  • Minimum Breakdown Voltage: 6.4V
  • Maximum Clamping Voltage: 9.2V
  • Peak Pulse Current: 163A
  • STAND-OFF voltage (Vwm): 5V
  • Temperature Range: -55°C to 150°C (TJ)
  • Power Dissipation (Pd): 1500W (1.5kW)
  • Application Field: communications and networking, computers and computer peripherals, imaging, video and vision, and industrial applications
  • Supply and Demand Status: Balanced
