RXEF110 Tyco Electronics RXEF110 Real Image RXEF110 label picture
Same model may have multiple batches, images only for reference.
RXEF110 Tyco Electronics RXEF110 Real Image RXEF110 label picture
RXEF110 Tyco Electronics RXEF110 Real Image RXEF110 label picture
Same model may have multiple batches, images only for reference.

RXEF110

Part No RXEF110
Manufacturer Littelfuse Inc.
Catalog PTC Resettable Fuses
Description PTC RESET FUSE 72V 1.1A RADIAL / Polymeric PTC Resettable Fuse 72V 1.1 A Ih Through Hole Radial, Disc
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Circuit Protection - PTC Resettable Fuses
Mfr Littelfuse Inc.
Series PolySwitch®, RXEF
Package Bag
Product Status Active
Type Polymeric
Voltage - Max 72V
Current - Hold (Ih) (Max) 1.1 A
Current - Trip (It) 2.2 A
Current - Max 40 A
Time to Trip 8.2 s
Resistance - Initial (Ri) (Min) 150 mOhms
Resistance - Post Trip (R1) (Max) 380 mOhms
Temperature Range - Operating -40°C ~ 85°C
Mounting Type Through Hole
Package / Case Radial, Disc
Size / Dimension 0.504" Dia x 0.118" T (12.80mm x 3.00mm)
Height - Seated (Max) 0.689" (17.50mm)
Lead Spacing 0.200" (5.08mm)
Approval Agency CQC, CSA, TUV, UL
Standard Package 500 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8533.40.8070
California Prop 65 Warning Information
Win Source Part Number 662114-RXEF110
Ultra Librarian 3D Model Ultra Librarian RXEF110 CAD Model

Description

The 662114-RXEF110 is a PolySwitch® RXEF series resettable fuse from Littelfuse Inc.

  • Series: PolySwitch® RXEF
  • Maximum Voltage Rating: 72V
  • Maximum Current Rating: 40A
  • Hold Current: 1.1A
  • Trip Current: 2.2A
  • Time to Trip: 8.2 seconds
  • Mounting Type: Through-hole
  • Package: Radial, disc
  • Temperature Range: -40°C to 85°C
  • Resistance: 150 mOhms
  • Approvals: CQC, CSA, TUV, and UL
  • Status: Active
  • REACH Regulations: Unaffected
