RF3059-000 Real Image
Same model may have multiple batches, images only for reference.

RF3059-000

Part No RF3059-000
Manufacturer Littelfuse Inc.
Catalog PTC Resettable Fuses
Description PTC Resettable Fuse 14A(hold) 23.8A(trip) 16VDC 100A 4.6W 0.002Ohm Radial 27.9 X 3.6 X 27.9mm Bulk
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Mounting SMD (SMT)
Case / Package Radial
Height - Seated (Max) 27.8892 mm
Hold Current 14 A
Lead Pitch 10.16 mm
Length 23.495 mm
Max Current Rating 100 A
Mount Through Hole
RoHS Compliant
Time to Trip 9 s
Trip Current 23.8 A
Width 2.8956 mm
Win Source Part Number 976044-RF3059-000
Categories PTC Resettable Fuses
Manufacturer Littelfuse Inc.
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian RF3059-000 CAD Model

Description

The Littelfuse Inc. 976044-RF3059-000 PTC resettable fuse is a reliable and safe solution for protecting electronic devices from overcurrent.

  • Manufacturer: Littelfuse Inc.
  • Win Source Part Number: 976044-RF3059-000
  • Type: PTC resettable fuse
  • Hold Current: 14 A
  • Trip Current: 23.8 A
  • Time to Trip: 9 s
  • RoHS: compliant
  • Mounting: through-hole
  • Lead Pitch: 10.16 mm
  • Supply and Demand Status: limited
