MICROSMD050F-2 Littelfuse Inc. MICROSMD050F-2 real image
Same model may have multiple batches, images only for reference.
MICROSMD050F-2 Littelfuse Inc. MICROSMD050F-2 real image
MICROSMD050F-2 Littelfuse Inc. MICROSMD050F-2 real image
Same model may have multiple batches, images only for reference.

MICROSMD050F-2

Part No MICROSMD050F-2
Manufacturer Littelfuse Inc.
Catalog PTC Resettable Fuses
Description POLYSWITCH 0.50A RESET FUSE SMD
Datasheet
MICROSMD050F-2 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Circuit Protection
Manufacturer Littelfuse Inc.
Packaging Reel - TR
Status Active
Type Polymeric
Voltage - Max 13.2V
Current - Max 40A
Current - Hold (Ih) (Max) 500mA
Current - Trip (It) 1A
Time to Trip 50ms
Resistance - Initial (Ri) (Min) 250 mOhm
Resistance - Post Trip (R1) (Max) 900 mOhm
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Dimension 0.127" L x 0.102" W (3.22mm x 2.58mm)
Thickness (Max) 0.024" (0.62mm)
Approvals CSA, TUV, UL
Win Source Part Number 023348-MICROSMD050F-2
Family Name MICROSMD
Introduction Date November 09, 2015
ECCN EAR99
Country of Origin China
Estimated EOL Date 2027
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Industrial, Computers & Computer Peripherals, Consumer Electronics, Imaging, Video & Vision, Communications & Networking, Automotive
Ultra Librarian 3D Model Ultra Librarian MICROSMD050F-2 CAD Model

Description

The Littelfuse Inc. 023348-MICROSMD050F-2 is a polymeric type circuit protection product that is used in various electronic applications.

  • Approvals: CSA, TUV, and UL approvals
  • Mounting: SMD (SMT)
  • Thickness: 0.024" (0.62mm)
  • Maximum Voltage: 13.2V
  • Maximum Current: 40A
  • Current Hold: 500mA
  • Current Trip: 1A
  • Time to Trip: 50ms
  • Resistance: 250 mOhm initial (Ri) (Min) and 900 mOhm post-trip (R1) (Max)
  • Supply and Demand Status: sufficient
  • Applications: industrial, computers & computer peripherals, consumer electronics, imaging, video & vision, communications & networking, automotive applications
  • Manufacturer: Littelfuse Inc.
