KRDB424 Littelfuse Inc. – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

KRDB424

Part No KRDB424
Manufacturer Littelfuse Inc.
Catalog Time Delay Relays
Description RELAY TIME DELAY 100MIN 10A 125V
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Mounting Type Chassis Mount
Relay Type Mechanical Relay
Function Off-Delay
Circuit SPDT (1 Form C)
Delay Time 1 Min ~ 100 Min
Contact Rating @ Voltage 10A @ 125VAC
Voltage - Supply 120VAC
Termination Style Quick Connect - 0.250" (6.3mm)
Timing Adjustment Method Screwdriver Slot
Timing Initiate Method Input Voltage, Trigger Signal
Package Bulk
Supply and Demand Status Shortage
Win Source Part Number 1508517-KRDB424
Ultra Librarian 3D Model Ultra Librarian KRDB424 CAD Model
