601-CS-D-P1 Littelfuse Inc. – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

601-CS-D-P1

Part No 601-CS-D-P1
Manufacturer Littelfuse Inc.
Catalog Monitor - Current/Voltage - Relay Output
Description PWR MON W/ EXT GF CT & DISP
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Type Ground Fault Sensing AC
Trip Status Energized High/Low
Trip Range 0.5 ~ 10A DC
Voltage - Supply 200 ~ 480VAC
Output Type Relay
Circuit SPDT (1 Form C)
Contact Rating @ Voltage 10A @ 240VAC
Mounting Type Chassis Mount
Package Bulk
Supply and Demand Status Shortage
Win Source Part Number 1506924-601-CS-D-P1
Ultra Librarian 3D Model Ultra Librarian 601-CS-D-P1 CAD Model
