1812L110/24DR Littelfuse Inc. 1812L110/24DR Real Image 1812L110/24DR label picture 1812L110/24DR label picture 3 1812L110/24DR real image 1812L110/24DR label picture 4
Same model may have multiple batches, images only for reference.
1812L110/24DR Littelfuse Inc. 1812L110/24DR Real Image 1812L110/24DR label picture 1812L110/24DR label picture 3 1812L110/24DR real image 1812L110/24DR label picture 4
1812L110/24DR Littelfuse Inc. 1812L110/24DR Real Image 1812L110/24DR label picture 1812L110/24DR label picture 3 1812L110/24DR real image 1812L110/24DR label picture 4
Same model may have multiple batches, images only for reference.

1812L110/24DR

Part No 1812L110/24DR
Manufacturer Littelfuse Inc.
Catalog PTC Resettable Fuses
Description FUSE PTC RESET 1.10A 24V 1812 / PTC Resettable Fuse 1.1A(hold) 1.95A(trip) 24VDC 20A 0.8W 0.5s 0.06Ohm SMD Solder Pad 1812 T/R
Datasheet
1812L110/24DR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Circuit Protection
Manufacturer Littelfuse Inc.
Packaging Reel - TR
Status Active
Type Polymeric
Voltage - Max 24V
Current - Max 20A
Current - Hold (Ih) (Max) 1.1A
Current - Trip (It) 1.95A
Time to Trip 500ms
Resistance - Initial (Ri) (Min) 60 mOhm
Resistance - Post Trip (R1) (Max) 200 mOhm
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Dimension 0.179" L x 0.128" W (4.55mm x 3.24mm)
Thickness (Max) 0.042" (1.07mm)
Approvals cURus, TUV
Win Source Part Number 005274-1812L110/24DR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name 1812L
ECCN EAR99
Country of Origin Taiwan
Halogen Free Not Compliant
Estimated EOL Date 2026
Ultra Librarian 3D Model Ultra Librarian 1812L110/24DR CAD Model

Description

1812L110/24DR PolySwitch Resettable Fuse

The 1812L110/24DR is engineered to offer dependable protection against overcurrent in a variety of electrical equipment. Its compact size and robust performance make it ideal for ensuring the longevity and safety of your devices.

  • Applications and Projects:
    • Industrial automation systems
    • Lighting projects
    • Computing equipment
    • Security systems
  • Key Features and Benefits:
    • Offers resettable protection to manage overcurrents efficiently
    • Highly responsive to electrical hazards, minimizing damage
    • Effective in maintaining system reliability
    • Compact 1812 packaging for space-constrained designs
  • Additional Details:
    • Maximum voltage of 24V
    • Nominal holding current of 1.1A
    • Proven track record of high cycle performance
