LTV-354T-A Real Image LTV-354T-A real image2199 LTV-354T-A real image2200
Same model may have multiple batches, images only for reference.
LTV-354T-A Real Image LTV-354T-A real image2199 LTV-354T-A real image2200
LTV-354T-A Real Image LTV-354T-A real image2199 LTV-354T-A real image2200
Same model may have multiple batches, images only for reference.

LTV-354T-A

Part No LTV-354T-A
Manufacturer Lite-On Inc.
Catalog Optoisolators - Transistor, Photovoltaic Output
Description OPTOISOLATOR 3.75KV TRANS 4SOP
Datasheet
LTV-354T-A Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Lite-On Inc.
Status Active
Number of Channels 1
Isolation Voltage 3750Vrms
Minimum DC Current Transfer Ratio 50% @ 1mA
Maximum DC Current Transfer Ratio 150% @ 1mA
Rise and Fall Time 4μs, 3μs
Input Type AC, DC
Output Type Transistor
Maximum Output Voltage 35V
Channel Output Current 50mA
Forward Voltage 1.2V
Continuous forward current- Max 50mA
Vce Saturation (Max) 200mV
Temperature Range - Operating -30°C to 110°C
Win Source Part Number 303741-LTV-354T-A
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Family Name LTV354T-A
Introduction Date December 26, 2001
ECCN EAR99
Estimated EOL Date 2023
Ultra Librarian 3D Model Ultra Librarian LTV-354T-A CAD Model

Description

The Lite-On LTV-354T-A is an optocoupler with a transistor output. The device has a maximum output voltage of 35V and an output current per channel of 50mA. The LTV-354T-A has a low Vce saturation of 200mV, which helps in reducing power consumption. The device has a rise/fall time of 4μs and 3μs, respectively. The supply and demand status of the device is sufficient.
